机床有多款规格，详细配置、机床价格请和工作人员联系！按要求选配
技术规格 | Description | 单位Units | M7130x1000 | M7130x1600 | M7130x2000 | ||
工作台尺寸（长x宽） | Size of work table(LxWx H) | mm | 1000x300 | 1600x300 | 2000x300 | ||
工作台最大纵向移动量 | Max.Longitudinal movement of worktable | mm | 1100 | 1700 | 2100 | ||
主轴中心到工作台的最大距离 | Max.Distance from the spindle centerline to the worktable surface | mm | 570 | 570 | 570 | ||
磨头最大横向移动量 | Max.Cross movement of grinding herd | mm | 350 | 350 | 350 | ||
磨头最大垂直移动量 | Max.Vertical movement of grinding head | mm | 400 | 400 | 400 | ||
磨头垂直进给手轮刻度值 | 每格 | Vertical movement of the grinding head by hand wheel | Every lattice | mm | 0.01 | 0.01 | 0.01 |
每转 | Each turn | mm | 1.00 | 1.00 | 1.00 | ||
快速升降电机 | 功率 | Rapid lifting motor | Power | KW | 0.37 | 0.37 | 0.37 |
转速 | Speed | R/min | 1440 | 1440 | 1440 | ||
砂轮尺寸(长x直径x宽) | Abrasive wheel dim (Lx DxW) | mm | 350x127x40 | 350x127x40 | 350x127x40 | ||
砂轮转速 | Speed of grinding wheel | r/min | 1440 | 1440 | 1440 | ||
电机总功率 | Total power of motor | KW | 9 | 10 | 12 | ||
砂轮主轴电机 | Power of spindle motor | KW | 5.5 | 5.5 | 5.5 | ||
油泵电机 | Power of oil pump motor | KW | 3 | 4 | 5.5 | ||
工作精度 | Processing accuracy | mm | 0.015/1000 | 0.015/1000 | 0.015/1000 | ||
表面粗糙度 | Surface roughness | um | Ra:0.63 | Ra:0.63 | Ra:0.63 | ||
包装尺寸（长x宽x高） | Package(LxW xH) | mm | 2800x1750x2350 | 4500x2000x2350 | 5500x2000x2350 | ||
机身净重 | Net.weight | Kg | 3500 | 3550 | 3600 | ||
